Match the bushing ID to your drill or reamer size, pick a body OD with enough wall for your jig plate, and choose a length of roughly 1.5 to 2 times the tool diameter. Leave about half to one drill diameter of chip clearance between the bushing and the part.
Press-fit bushings (ANSI type P and H) are pressed permanently into the jig plate. Renewable bushings (slip type S and fixed type F) sit in a hardened liner and are held by a lock screw or clamp, so they can be replaced or swapped without pressing.
Yes. We quote inch bushings to ANSI/ASME B94.33 and metric bushings to DIN 172, DIN 173 and DIN 179, plus liners, lock screws, clamps and specials.
Send us a written quote for the same bushing specification and quantity. If it is lower than ours, we match it.
Yes. Special IDs, extended heads, oil grooves, carbide and stainless bushings can be quoted. Attach a drawing or describe the part in the quote notes.
Each quote lists a ship date for every line, so you know when the parts leave before you place the order.
